| Brand |
Mushkin Enhanced |
| Series |
Element |
| Model |
MKNSSDEV1TB-D8 |
| Type |
PCIe NVMe Internal Solid State Drive (SSD) |
| Used For |
Consumer |
Physical
|
| Form Factor |
M.2 2280 |
| Capacity |
1TB |
| Interface |
PCIe Gen3 x4 NVMe 1.3 |
| Controller |
– |
| Height |
80mm |
| Width |
22mm |
| Depth |
3.8mm |
| Weight |
7g |
Performance
|
| Max Sequential Read |
Up to 2000MB/s |
| Max Sequential Write |
Up to 1600MB/s |
| Seek Time |
<0.1ms |
| TBW |
– |
| MTBF |
1,500,000 hours |
Features
|
| Features |
MEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected |
| – Built-in LDPC ECC provides the most-powerful error correction method in use today |
| – End-to-end data path protection |
| – Global wear-leveling evens program/erase counts across data blocks to extend lifespan |
| Host Memory Buffer (HMB) uses system DRAM to boost performance |
| SLC caching accelerates burst performance |
| Supports SMART |
| NVMe Security Erase support |
| NVMe Deallocate function support (NVMe equivalent of TRIM command) |
| High-reliability 3D NAND flash |
| S.M.A.R.T. support |
| User-upgradeable firmware |
| Temperature sensor |
| RoHS, FCC, CE |
| Power Consumption (Idle): 0.03W |
| Power Consumption (Active): 5W |
| Max sequential speeds measured using CrystalDiskMark 6.0.2 x64. |
Environmental
|
| Operating Temperature |
0°C-70°C |
| Storage Temperature |
-40°C-85°C |
| Max Shock Resistance |
1500G |
| Power Supply |
3.3V DC |
